monitor
24B3CA2
Høytytende klarhet med 23,8" FHD-skjerm med 100Hz oppdateringsfrekvens og HDMI
Styrk utsikten din, koble til smart
Vi introduserer det nyeste tilskuddet til B3-serien – en strålende 23,8-tommers skjerm med IPS-panel for fantastiske bilder med 1920 x 1080 oppløsning og 100 Hz oppdateringsfrekvens. Hvis du leter etter en skjerm i kompakt størrelse med jevn opplevelse, er 24B3CA2 det ideelle valget. Med én enkelt USB-C-kabel er også videosignal, strømforsyning og dataoverføring tilgjengelig, noe som vil forbedre produktiviteten din. Enten du jobber eller studerer kan du nyte en mer komfortabel og hyggeligere seeropplevelse med den kompakte skjermstørrelsen til 24B3CA2.

USB-C

HDMI

FHD oppløsning

Integrerte høyttalere

1 ms MPRT-responstid

Adaptive sync
Spesifikasjoner
- Bezel type (front)4 side like
- Light FX (RGB)
- Removable stand
- Speakers
- Speaker power2 W x 2
- Built-in Microphone
- Kensington Lock
- I/O define: Connectors on rear cabinetVertical insert
- Quick release function
- Sound enhancementNo
- VESA Mount screw SpecM4 x 10
- VESA Mount SupportYes
- MonitorWebcamNo
- Bezel Colour (front)Black
- Bezel finishing (front)Texture
- Cabinet colour (backside)Black
- Cabinet finishing (backside)Texture
- Vesa wallmount100x100
- Digital HDCP (HDMI version)HDCP 1.4
- USB-C connectivityUSB-C 3.2 x 1 (DP alt mode, upstream, power delivery up to 65 W)
- USB Display Link
- USB Hub
- USB fast charge port
- Audio Input
- Microphone in
- mini USB (for external keypad)No
- MST / Daisy chain (DP out or TBT out)
- Thunderbolt in0x
- Thunderbolt out0x
- PD for USB C/TBTUSB C1 : PD=65W, PD3.0, 5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A
- Microphone out
- D-SUB (VGA)0x
- DVI0x
- RJ45No
- HDMIHDMI 1.4 x 1
- USB-generasjonUSB 3.2 (Gen 1), 5 Gbit/s
- USB type downstream2 x USB-A
- Audio OutputHeadphone out (3.5mm)
- USB Type upstream1x USB-C (DP Alt Mode), USB-C PD:65W
- Screen size (inch)23.8
- Screen size (cm)60.5
- Flat / CurvedFlat
- Display viewing Area (HxW) in mm527,04 x 296,46
- Display hardness3H
- Panel treatmentAntiglare (AG)
- Pixel Pitch (mm)0.2745
- Pixels per Inch93.0
- Panel resolution1920x1080
- Aspect ratio16:9
- Panel typeIPS
- Backlight typeWLED
- Max Refresh rate100 Hz
- Response time GtG4 ms
- Response time MPRT1 ms
- Static contrast ratio1300:1
- Dynamic contrast ratio20M:1
- Viewing angle (CR10)178/178
- Display colours16.7M (6bits+FRC)
- Brightness in nits250 cd/m²
- FargespekterNTSC 72%
- OD Response (typical)4 ms GtG
- Panel Haze Value25%
- Picture enhancement
- Support 1:1 function
- Local Dimming ZonesGlobal Dimming
- Resolution nameFHD
- Tilt-5 (+3/-0) ~ +23 (-3/+0)
- Auto Pivot (G sensor)No
- EAN4038986141468
- Warranty period3 years
- MTBF30.000 hours (with backlight)
- Accessory box
- OSD languagesEnglish, Ukranian, Turkish, Polish, German, Portuguese, Spanish, French, Finnish, Korean, Japanese, Chinese (simplified), Chinese (traditional), Swedish, Dutch, Italian, Kroatian, Russian, Czech
- Operation SystemWindows 8.1/10/11, MacOS
- Power supplyInternal
- Power source100 - 240V 50/60Hz
- Power consumption on (typical) in watts35.0
- Power consumption standby in watts0.5
- Power consumption off in watts0.3
- Energy classE
- Power LED indicator (Operation)White/Blue
- Power LED indicator (Standby)Orange
- Power Switch
- Smart Power
- Product dimensions incl. base (WxHxD) mm542.4 x 412.1 x 202.3
- Product dimensions excl. base (WxHxD) mm542.4 x 316.2 x 44.6
- Packaging dimensions (WxHxD) mm614 x 394 x126
- Packaging dimensions (WxHxD) mm (CN)614 x 394 x126
- Gross weight incl. package (in kg)5.28
- Produkt med stativ (kg)3.36
- Gross weight incl. package (in kg) (CN)5.28
- Produkt uten stativ (kg)3.04
- Energy starEnergy star 8
- ECMA Eco declaration
- Product carbon footprint (PCF)
- WEEE
- REACH compliant
- RoHs compliant
- HF
- PVC/BFR free housing
- Mercury free
- Recycable packaging material100 % recycable
- Post-consumer recycled plasticNo (B2C)
- Low Halogen
- Carton materialPaper
- TCO CertifiedNo
- Sync technology (VRR)Adaptive Sync
- Digital Signal Frequency Vertical48-100Hz
- Digital Signal Frequency Horizontal30-115kHz
- Colour space (sRGB) CIE 1931 %102.7
- Colour space (sRGB) CIE 1976 %102.5
- Colour space (DCI-P3) CIE 1931 %75.7
- Colour space (DCI-P3) CIE 1976 %81.6
- Colour space (Adobe RGB) CIE 1931 %76.1
- Colour space (Adobe RGB) CIE 1976 %87.8
- Colour space (NTSC) CIE 1931 %72.7
- Colour space (NTSC) CIE 1976 %89.4
- Colour space (BT 709) CIE 1931 %102.7
- Colour space (BT 709) CIE 1976 %102.5
- Colour space (BT 2020) CIE 1931 %54.3
- Colour space (BT 2020) CIE 1976 %59.5
- Flicker-FreeFlicker Free
- eyeSafe (TUV) hardware
- KVMNo
- Blue Light TechnologyLow Blue Light
- HDMI cable1.5
- USB-C to C cable1.8
- RS232
- Power Cable
